GL-B2200 Tri-Band Wi-Fi Mesh Router

MEET GL-B2200

Integrated Mesh Wi-Fi System with Tri-Band Wi-Fi


COMING SOON

Tri-Band Wi-Fi Mesh Router

With Tri-band Wi-Fi mesh technology, GL-B2200 grid provides wide-spread and stable Wi-Fi coverage at home. You can enjoy high speed and secured Wi-Fi anywhere at home.


400Mbps (2.4G) + 2x867Mbps (5G) Combined Wi-Fi Speed
Built-in Bluetooth or Zigbee Module*
2 x Gigabit Ports
Supports MU-MIMO

Learn More

Smart Home Gateway Solution

An OpenWrt Home Gateway for Your Internet of Things

Smart Home Gateway
Connecting Smart Home Sensors
IOT GATEWAY FOR YOUR SMART DEVICES

Pair Smart Devices with BLE & Zigbee Module

It is based on proven Silicon Labs chipset, low power consumption, multi-protocol supportable (BLE and Zigbee could switch by SW updating), and on-board antenna supportable. With BLE and Zigbee, you can have a quick and easy access on your smart devices.


Smart Home Appliance
LARGE STORAGE COMPATIBILITY

8GB eMMC storage and Bluetooth IoT System

Pre-download video streaming and websites up to 8GB eMMC. Bluetooth IoT is implemented for data storage. Therefore, buffering time on loading your favourite episodes and your frequent browsed websites is almost eliminated.

8GByte EMMC
25+ VPN SERVICE PROVIDERS FOR YOUR SELECTION

Facilitating Secure IoT Communications

GL-B2200 creates a secure network for devices that process sensitive information such as ATMs, Point-of-Sales (POS) and more, encrypting their 4G LTE or Wi-Fi traffic via a VPN tunnel for secure access to the Internet or remote services.


GoodCloud makes it easy to manage and monitor our devices anytime, anywhere, and multiple GL.iNet devices at the same time. You can view the real-time statistics, setup VPN server and client, manage client connection list, and etc through the App or web admin panel.

Learn More

Web Service API

IoT Device Modeling

Control Logic Building

Data Analysis

High Speed
Gigabit
Ethernet
MU-MIMO
Multi-User
MIMO
Fast Wifi
Tri-band
Wi-Fi
VPN Server/Cilent
VPN Client/
Server
Mesh
Mesh
Network
8GB eMMC
Large
Storage
Bluetooth
Bluetooth
ZigBee
Zigbee
(Optional)

Specification

Interface 1 x WAN Ethernet port
1 x LAN Ethernet port
1 x LED
1 x Type-C port
1 x WPS Button
CPU IPQ4019 Quad-core ARM, @717MHz SoC
Memory / Storage DDR3L 512MB / FLASH 4MB NOR FLASH + EMMC 8GB
Antennas Internal
Protocol 802.11a/b/g/n/ac
Wi-Fi Speed 400Mbps (2.4GHz), 2x867Mbps(5GHz)
TX power Max. 23dBm
Ethernet Port 2 x 10/100/1000M
Power Input Type-C, 5V/3A
Power Consumption <15W
Working Temperature 0 ~ 40°C (32 ~ 104°F)
Storage Temperature -20 ~ 70°C (-4~158°F)
Dimension / Weight 151 x 66.5 x 190.5mm
