GL-S10 BLE IoT Gateway

MEET GL-S10

Connecting IoT Devices to the Cloud

Shop Now Contact Sales

Bluetooth IoT Gateway

GL-S10 is an ESP32-powered BLE to MQTT IoT gateway. It can be used to facilitate communication between your beacons and servers, such as MQTT broker and AWS IoT. GL-S10 also comes with an optional beacon for testing and a tool app for fast and easy deployment.


Built-in Bluetooth Module
Support MQTT and PoE Power Supply
Built with ESP32

*This product cannot be used as a WiFi Access Point
Learn More View Online Guide

How GL-S10 Works

The GL-S10 is an IoT gateway device that supports BLE and Wi-Fi, providing a cost-effective solution for transmitting BLE broadcast data to the cloud. BLE supports GAP and GATT certification and can be used as either Master or Slave to connect and communicate with other BLE devices. GL-S10 can use Wi-Fi as a Station to connect to a parent route or can connect to the Internet through a WAN port. It has a built-in standard MQTT Client that can connect to any standard MQTT Servers to forward incoming BLE messages to the cloud server.

Smart ESP32 Bluetooth IoT Gateway

The GL-S10 is ideally deployed in warehouses, shopping malls, airports, exhibition halls, tourist attractions and other scenarios for personnel management, asset management, environmental monitoring, indoor navigation, etc.

GL-S10 deployed in warehouses
GL-S10 hardware

A Minimalist IoT Communication Solution

GL-S10 is a compact BLE IoT gateway that supports Wi-Fi and MQTT protocols. It is designed to be an essential, low power consumption and low-cost transmission device.

Comes with a Tool App

for easy set up & configuration

  • app-store
  • google play

Application Scenarios

Asset Management

Environmental Monitoring

Healthcare Device Monitoring

Indoor Position Tracking

Bluetooth 4.2
Bluetooth 4.2
AWS IoT
AWS IoT
PoE
PoE
MQTT
MQTT
Real-time Scanning
Real-time Scanning
Wi-Fi 150Mpbs
Wi-Fi 150Mbps

Specification

Interface 1 x Ethernet port
3 x LEDs
1 x Reset Button
CPU ESP32-D0WD
Memory / Storage SRAM 520KB + PSRAM 8MB; 4MB Nor
Protocol IEEE 802.11 b/g/n
Wi-Fi Speed 2.4GHz (150Mbps)
Ethernet Port 1 x 10/100M
LEDs BLE / Internet / Power
Bluetooth V4.2, BLE
Power Input 5V/1A DC Input or PoE Power Input
Power Consumption Normal Operating Consumption: <0.5W / Operating at Full Capacity: <1.5W
Working Temperature 0~40°C (32~104°F)
Storage Temperature -20~70°C (-4~158°F)
Dimension / Weight 57 x 57 x 25mm, 53.6g
Downloadables Tool App |  Product Flyer
