gl-inet products GL-AR300M

GL-AR300M

  • Powered by Qualcomm QCA9531 SoC, 650MHz CPU
  • 300Mbps high speed
  • 128MB RAM
  • 128MB Nand (not available in Lite version) + 16MB Nor dual flash, space doesn’t matters anymore
  • Small, light, easy to use
  • OpenWrt pre-installed
  • UART, PCIe interfaces.
  • External antenna optional support

GL-AR300M pushes the hardware specs of a mini router to the limit by using 650Mhz CPU and 128M nand flash, making it a portable PC in your pocket.

With 128M nand flash, storage is not a problem for OpenWrt. It is super fast. Check how the performance is improved compared to Nor flash.

CPU QCA9531, 650MHz
Memory DDRII 128MB
Storage 16MB Nor + 128MB Nand dual flash
Interfaces 1 WAN, 1 LAN, 1 USB2.0, 1 micro USB (power), 1 Reset button, PCIe, UART
Frequency 2.4GHz (5G addon)
Transmission rate 300Mbps
Max Tx Power 20dBm
Protocol 802.11 b/g/n
External Storage support FAT32/EXFAT/EXT4/EXT3/EXT2/NTFS
Webcam support MJPG, YUV
DIY features UART, GPIO, PCIe, 3.3V & 5V power port
External antenna support Yes
PoE support No
Power input 5V/1A
Power consumption <2W
Dimension, Weight 58*58*25mm, 39g

AR300M specific Docs: https://docs.gl-inet.com/hardware/ar300m/

Firmware can be found at: http://download.gl-inet.com/firmware/ar300m/

AR300M User Guide can be found at: minirouter_user-guide_AR300M_20170628

AR300M-Lite User Guide can be found at: minirouter_user-guide_AR300M-Lite_20170628

GL-AR300M16

  • with internal antenna
  • 2.4G version only
  • Two Ethernet ports
  • Nor 16MB flash only
Shop Now

GL-AR300M16-Ext

  • two small external antennas
  • 2.4G version only
  • Two Ethernet ports
  • Nor 16MB flash only
Shop Now

GL-AR300M

  • with internal antenna
  • 2.4G version only
  • Two Ethernet ports
  • With Nand 128MB flash
Shop Now

GL-AR300M-Ext

  • with two small external antennas
  • 2.4G version only
  • Two Ethernet ports
  • With Nand 128MB flash
Shop Now

GL-AR300M-Lite

  • with internal antenna
  • 2.4G version only
  • One Ethernet ports
  • Nor 16MB flash only
Shop Now

GL-AR300MD

  • with internal antenna
  • 2.4G and 5G dual band version
  • Two Ethernet ports
  • With Nand 128MB flash
Discountinue
